Product Description
Key Features & Benefits
-
Modular Scalability: Start with 50kVA and scale to 100kVA or 150kVA within the same cabinet. No need for a large-scale electrical overhaul when you need more power.
-
Unity Power Factor: Provides more active power than traditional 0.9 PF units, allowing you to support more servers with a smaller kVA rating.
-
Industry-Leading Efficiency: Achieves up to 97% efficiency in double-conversion mode and up to 99% in Eco-mode, significantly lowering Total Cost of Ownership (TCO).
-
LIFE™ Services Integration: Features Vertiv’s remote diagnostic and preventive monitoring service, which provides 24/7 expert analysis to ensure maximum uptime.
-
Flexible Battery Configurations: The 150kVA frame can be configured with internal batteries (for shorter runtimes) or connected to external battery cabinets for extended backup needs.
-
Intuitive Touchscreen: A 10-inch color touchscreen display provides clear, real-time data on system status, load, and battery health.
Technical Specifications
| Feature | Specification |
| Power Rating | 50 kVA / 50 kW (Scalable to 150kVA) |
| Phase | 3-Phase (Input & Output) |
| Topology | Double-Conversion Online |
| Efficiency | ~97% (Standard) / 99% (Eco-mode) |
| Dimensions (WxHxD) | 44.1″ x 78.7″ x 39.4″ (1120 x 2000 x 1000 mm)* |
| Weight (Empty Frame) | ~1,250 lbs (567 kg) |
| Input THDi | < 3% (Generator Friendly) |
| Audible Noise | < 65 dBA @ 1 meter |
