Product Description
Key Features & Benefits
-
Energy Saver System (ESS): Achieves a staggering 99% efficiency by safely bypassing the inverter when utility power is within acceptable limits, switching to full double-conversion in less than 2ms if a fault is detected.
-
Powerware HotSync® Paralleling: This patented technology allows you to parallel up to four units for capacity or redundancy without needing a master/slave communication cable—eliminating a common failure point found in other systems.
-
Advanced Battery Management (ABM): Uses a unique three-stage charging technique that significantly extends battery life (up to 50%) and provides advanced notice of battery failure.
-
Low Input THDi: Maintains less than 4.5% total harmonic distortion at the input, making it exceptionally “generator friendly” and reducing the need to oversize your backup generators.
-
Flexible Footprint: One of the most compact units in its class, designed with front-service access so it can be installed directly against a wall or in a corner.
Technical Specifications
| Feature | Specification |
| Power Rating | 160 kVA / 144 kW (0.9 Power Factor) |
| Phase | 3-Phase (Input & Output) |
| Topology | Double-Conversion Online |
| Efficiency | 94% (VFI Mode) / 99% (ESS Mode) |
| Input Voltage | 480V, 208V, or 600V (Configurable) |
| Output Voltage | Matches Input (e.g., 480V or 208V) |
| Weight | ~1,060 lbs (UPS unit only) |
| Dimensions (WxHxD) | ~35.6″ x 73.7″ x 31.6″ |
