Product Description
Key Features & Benefits
-
Hot-Swappable Modularity: All major components: power modules, battery modules, and intelligence modules can be replaced or added while the system is online, reducing Mean Time to Repair (MTTR) to nearly zero.
-
Scalable Power & Runtime: Start at 20kVA and scale up (depending on the frame size, often to 40kVA or 100kVA) by simply sliding in additional 10kW power modules.
-
Built-in Redundancy: Supports N+1 module-level redundancy, ensuring that the failure of a single power or intelligence module does not drop the load.
-
High Efficiency: Operates at up to 95% efficiency even at low loads (25%), significantly lowering electricity and cooling costs.
-
Integrated Distribution: Features an “all-in-one” design options that include an integrated 39-pole PDU and maintenance bypass, saving valuable floor space.
Modular: 20kVA config. Scalable 10-40kVA. Other configs available on request.
Technical Specifications
| Feature | Specification |
| Power Rating | 20 kVA / 20 kW (Unity Power Factor) |
| Phase | 3-Phase (Input & Output) |
| Topology | Double Conversion Online |
| Nominal Voltage | 208V (Input/Output) or 480V (depending on sub-model) |
| Efficiency | Up to 95% (99% in ECO Mode) |
| Form Factor | Standard IT Rack (42U) |
| Communication | Pre-installed Network Management Card (NMC) |
| Redundancy | N+1 Capable |
